DIGITAL FABRICATION WORKSHOP!
@TAMU | COLLEGE OF ARCHITECTURE. COLLEGE STATION. TX. USA.
Gabriel Esquivel presents:
SEPTEMBER 2011 | 20 Hours.
COMPUTATIONAL DESIGN – BIO-RE / GENERATIVE DESIGN
Prototypical Avant-garde architectonic structures.
PARAMETRIC ANALYSIS | RHINOCEROS + GRASSHOPPER
Objectives:
The student will develop computational design skills to afford integral design solutions through Grasshopper visual scripting; this will lead the design layout into qualitative research through contemporary methodologies in the building and fabrication process: Laser cut, cnc milling and 3D printing.
FRAMEWORK.
INTERACTIVE OBJECTS_visual [OOP] programming.
- Parametric geometry generation: Creating parametric geometry by points and curves generation with specific relationship constraints.
- Pattern MACRO/micro control: Creating special surface conditions, providing density, reactivity and efficiency; developing a phenomenological organic progressive interactivity and functionality to the user.
- Digital Fabrication: Design computational protocols to describe structure morphology as a set of linear developable elements. Those singular elements can then be unrolled and cut out of flat sheets of material.
COMPOSE / DECOMPOSE / RE | COMPOSE
Generative process:
1. Constraints definition.
2. Pattern generation.
3. Geometry parametric optimization.
- Geometric transformations from one state to other.
- Members generated within a structural network.
- Pattern reactivity programming into double curvature surfaces.
4. Fabrication Layout.
5. Fabrication and physical modeling.
______________________________________________
Workshop requierments:
A CAD software knowledge.
Rhinoceros 4.0 Installed.
Rhino Patch SR9.
Grasshopper 8.0051 Installed. (Latest)
Paper, pen, cutter.
Registry System.
1. Fill the form here:
http://bioarchitecturestudio.wufoo.com/forms/q7x3s5/
2. Pay your fee at:
ONLINE Workshop Payment Paypal.
OR
FOR USD DEPOSITS & INTERNET BANK TO BANK TRANSACTIONS.
BANK: BANORTE
To: David Hernández Melgarejo.
ACCOUNT: 0674193884
SWIFT: MENOMXMT
3. Send a copy of your deposit ticket or payment confirmation to:
bioarchitecturestudio@gmail.com with copy to gabe00fab@yahoo.com
I will send you an e- mail confirming your registration.
Thank you & see you soon!
David Hernández Melgarejo
___________________________________________________
Rhinoceros & Grasshopper resources:
http://download.rhino3d.com/rhino/4.0/evaluation/download/ (Rhinoceros 4.0 SR9 Evaluation)
http://download.rhino3d.com/Grasshopper/1.0/wip/download/ (Grasshopper DOWNLOAD)
BIO|ARCHITECTURE STUDIO
